TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals. It provides 2NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHSEACh).
| Brand | Schneider Electric |
|---|---|
| Green_premium_status | TRUE |
| [Ue] rated operational voltage | 690 V AC 25…400 Hz |
| ambient air temperature for operation | -25-50 °C |
| ambient air temperature for storage | -50-80 °C |
| Depth | 35 mm |
| Height | |
| Width | |
| Compatibility code | LA1 |
| Connections terminals | screw clamp terminals 1 cable(s) 0.34-1.5 mm²flexible with cable end |
| Ip degree of protection | IP20 conforming to IEC 60529 |
| supplier sku | LA1KN20 |
| Main pole contacts | 2 NO |
