GV2RT10 – Motor circuit breaker, TeSys Deca, 3P, 4-6.3 A, thermal magnetic, screw clamp terminals

Description

TeSys GV motor circuit breaker, 3 poles (3P), 6.3A690V, for high starting current peak motor applications 2.2kW@400V. It provides a thermal-magnetic protection with a thermal setting range 4-6.3A, a magnetic tripping level at 20xIn, high breaking capacity Icu 100kA@400V. Connection by screw clamp terminals. Start-stop control by toggle guaranteed for 100 000 cycles AC-3. It can be used for protection of 3-phase transformer applications. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHSEACh).

Additional information

Brand	Schneider Electric
Green_premium_status	TRUE
[Ue] rated operational voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage	6 kV conforming to IEC 60947-2
ambient air temperature for operation	-20-60 °C
ambient air temperature for storage	-40-80 °C
Depth	78.5 mm
Height
Width
[in] rated current	6.3 A
Breaking capacity	100 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2
Compatibility code	GV2RT
Control type	toggle
Device application	motor protection
Electrical durability	at 415 V
Ip degree of protection	IP20 conforming to IEC 60529
Mechanical durability	100000 cycles
supplier sku	GV2RT10
