LC1DT60AE7 – TeSys Deca contactor – 4P(4 NO)

Description

TeSys D contactor, 4 poles (4NO), for non-inductive load applications up to 60A440V AC-1. It provides a 48V 5060Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connection by EverLink BTR screw connectors and control by screw clamp terminals. For operating rates until 3600 cycleshour and environments until 60u00b0C, it procures high reliability and durability. Compact (70mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHSEACh).

Additional information

Brand	Schneider Electric
Green_premium_status	TRUE
[Icw] rated short-time withstand current	100 A – 1 s for signalling circuit
[Ie] rated operational current	60 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
[Ue] rated operational voltage	power circuit: <= 300 V DC
[Uimp] rated impulse withstand voltage	6 kV conforming to IEC 60947
ambient air temperature for operation	-40-60 °C
ambient air temperature for storage	-60-80 °C
Depth	120 mm
Height
Width
Compatibility code	LC1D
Connections terminals	control circuit: screw clamp terminals 1 cable(s) 1-4 mm²flexible with cable end
Electrical durability	1.4 Mcycles 60 A AC-1 at Ue <= 440 V
Ip degree of protection	IP20 front face conforming to IEC 60529
Mechanical durability	6 Mcycles
supplier sku	LC1DT60AE7
Auxiliary contacts	1 NO + 1 NC
Coil voltage	48 V AC
Main pole contacts	4 NO
